Aura — Google SDE Interview Coach

Aura is a real-time AI-powered Google SDE interview coach built on the Google ADK + Gemini Live native audio stack with LiveKit WebRTC transport and Vertex AI persistent session memory.

This repo is now in a hackathon-ready state: the core demo flow is implemented, locally testable, deploys on Google Cloud Run, and includes the final spoken scoring and memory continuity features that matter in a live judging session.

Core Features

Real-time voice interview agent with interruption handling and Gemini server-side VAD.
Four-round Google-style interview flow covering behavioural, coding, system design, and debrief.
Live spoken per-round scoring on a clear 1-4 scale, plus post-call rubric grading, answer feedback, and exportable session summary.
Candidate progress view for named users, showing recent sessions, average rubric score, and question volume.
Named-user interview state persistence across restarts, carrying forward asked questions, rubric grades, and answer notes.
Self-healing Vertex AI session-service recovery for repeated session persistence failures.
Google Cloud deployment on Cloud Run with Artifact Registry, Secret Manager, Vertex AI, Terraform, and Cloud Build CI/CD.

Demo Value

Why this is a strong live demo:

It is visibly multimodal: the candidate speaks naturally, Aura responds with low-latency voice, and the UI shows live transcript and session state.
It demonstrates real continuity: named users come back to preserved notes, grades, and prior round context instead of starting from zero.
It closes the feedback loop during the session: Aura can now speak a clear round score out of 4 before wrap-up, instead of hiding evaluation until the end.
It is actually deployable: the same repo includes Cloud Run, Cloud Build, Artifact Registry, Secret Manager, and Terraform infrastructure.

Layer	Technology
Agent framework	Google ADK (`google-adk`) — `LlmAgent`, `VertexAiSessionService`
Voice model	`gemini-live-2.5-flash-native-audio` via Vertex AI bidi stream
WebRTC transport	LiveKit (`livekit`, `livekit-api`)
Session memory	Vertex AI Agent Engine (`VertexAiSessionService`) with named-user state snapshots plus automatic recovery after repeated session-service failures
Infra	Google Cloud only (Cloud Run, Artifact Registry, Secret Manager, Vertex AI)
Backend	FastAPI + Python 3.11, containerised on Cloud Run
Frontend	Vite + React + LiveKit JS SDK
IaC	Terraform + Cloud Build CI/CD

Architecture

ASCII overview

Browser mic → LiveKit WebRTC → PCM16 @ 16 kHz
                                    ↓
           Silero VAD (UI-only hints)     ← bot/audio/silero_vad.py
                                    ↓
                         Gemini Live (Vertex AI)      ← server-side VAD
                         gemini-live-2.5-flash-native-audio
                                    ↓
Browser speaker ← LiveKit WebRTC ← PCM16 @ 24 kHz ← Gemini audio response

VAD strategy — Gemini server-side turn detection + local UI hints

Aura uses Gemini's built-in server-side VAD for actual turn detection and interruption semantics. A lightweight local Silero VAD is still used only for fast UI speaking indicators and STS timing, not for deciding when Gemini should end a turn.

Server VAD is configured via RealtimeInputConfig → AutomaticActivityDetection:

Parameter	Value	Effect
`silence_duration_ms`	`600`	600 ms of silence ends a turn — balanced: fast response without premature cuts
`prefix_padding_ms`	`200`	Includes 200 ms of audio before speech start — captures leading consonants

Latency analysis

Approach	End-of-speech → first audio byte	Notes
Server VAD (current)	~150–300 ms	VAD runs inside Gemini's inference pipeline; no round-trip penalty
Pure silence threshold (no VAD)	~300–500 ms	Simple but clips fast speakers; misses barge-in

Server VAD wins on latency because:

VAD judgment happens inside the same process as the LLM — no extra network hop
Barge-in (interruption) is handled natively without any muting gate on the send path
silence_duration_ms=800 is the only mandatory wait; the 150 ms figure applies when the model starts generating immediately after speech ends

Full diagram and design decisions: see Architecture section above.

Local Development

Prerequisites

Python 3.11+, uv
Node.js 20+
A LiveKit Cloud project (free tier works)
A Google Cloud project with Vertex AI enabled or a Google AI Studio API key

1. Clone and install

git clone https://github.com/srthorat/aura-sde-interview-agent.git
cd aura-sde-interview-agent
cp .env.example .env
# Fill in .env — see section below
uv sync

2. Configure `.env`

Minimum required values:

# LiveKit
LIVEKIT_URL=wss://your-project.livekit.cloud
LIVEKIT_API_KEY=your_livekit_api_key
LIVEKIT_API_SECRET=your_livekit_api_secret

# Google Cloud (Vertex AI path — recommended)
GOOGLE_CLOUD_PROJECT_ID=your-gcp-project-id
GOOGLE_CLOUD_LOCATION=us-central1
# Authenticate with: gcloud auth application-default login

# --- OR --- Google AI Studio (preview path, no GCP project needed)
# GEMINI_MODEL=preview
# GOOGLE_API_KEY=your_ai_studio_api_key

3. Run the backend

# Optional: use a non-default port for local work
# export PORT=7863

uv run python -m bot.bot
# Listening on http://localhost:${PORT:-7862}

4. Run the frontend (separate terminal)

cd frontend
nvm use   # picks Node 20 from .nvmrc automatically
npm install
npm run dev
# http://localhost:3000

Open http://localhost:3000, enter a User ID (1–10), click Connect, and speak.

5. Build the frontend for the backend-served app

The FastAPI app serves static files from frontend/dist. For the integrated app on the backend port, build the frontend first:

cd frontend
nvm use
npm install
npm run build

Then run the backend and open http://localhost:${PORT:-7862}.

6. Single-container run (Docker)

cp .env.example .env   # fill in values

# Optional local override
# echo 'PORT=7863' >> .env

docker compose up --build -d
docker compose ps
curl http://localhost:${PORT:-7862}/health

Open http://localhost:${PORT:-7862}.

Local setup used in this repo right now

If you want the same flow we are using during development:

cp .env.example .env

# Edit .env and set your real LiveKit / Google values.
# If you want the backend on 7863 instead of 7862:
# PORT=7863

cd frontend
nvm use
npm install
npm run build

cd ..
uv sync
uv run python -m bot.bot

Open http://localhost:7863 if PORT=7863, otherwise http://localhost:7862.

Session Persistence

Aura remembers each candidate's interview history (questions asked, scores, round progress) across reconnects. There are three tiers — use the one that fits your deployment:

Tier	Env var	Survives	Best for
Vertex AI Agent Engine	`VERTEX_AI_REASONING_ENGINE_ID`	Container restarts, Cloud Run scale-out, server replacement	Production / Cloud Run
File-based	`SESSION_PERSIST_DIR`	Process restarts (with Docker volume mount)	Single-VM / local dev
In-memory	(neither set)	Current process only	Quick testing

Tier 1 — Vertex AI Agent Engine (recommended for Cloud Run)

This uses Google-managed storage so sessions survive any restart, upgrade, or scale event.

Step 1 — Enable the API

gcloud services enable aiplatform.googleapis.com \
  --project=YOUR_PROJECT_ID

Step 2 — Create the Reasoning Engine resource

The Reasoning Engine is just a named container for sessions — no code is deployed to it.

gcloud ai reasoning-engines create \
  --display-name="aura-sessions" \
  --region=us-central1 \
  --project=YOUR_PROJECT_ID

The output will look like:

Created reasoning engine: projects/YOUR_PROJECT_ID/locations/us-central1/reasoningEngines/1234567890123456789

Note the numeric ID at the end (e.g. 1234567890123456789).

Step 3 — Grant the service account access

The identity running the bot needs aiplatform.user on the project:

# For local dev — your personal account
gcloud projects add-iam-policy-binding YOUR_PROJECT_ID \
  --member="user:YOUR_EMAIL" \
  --role="roles/aiplatform.user"

# For Cloud Run — the Cloud Run service account
gcloud projects add-iam-policy-binding YOUR_PROJECT_ID \
  --member="serviceAccount:YOUR_SA@YOUR_PROJECT_ID.iam.gserviceaccount.com" \
  --role="roles/aiplatform.user"

Step 4 — Set the env var

In .env (local) or Cloud Run environment:

VERTEX_AI_REASONING_ENGINE_ID=1234567890123456789

Comment out or remove SESSION_PERSIST_DIR — when VERTEX_AI_REASONING_ENGINE_ID is set it takes priority.

Step 5 — Restart and verify

# Local
uv run python -m bot.bot
# Logs should show:
# [adk] Using VertexAiSessionService (engine: 1234567890123456789)

# Docker
docker compose up -d
docker compose logs | grep "VertexAi\|session"

Tier 2 — File-based persistence (single VM / local dev)

Sessions are written as JSON files to a local directory. Works without any GCP setup.

Add to .env:

SESSION_PERSIST_DIR=/data/aura-sessions

For Docker, mount a host volume so data survives container replacement:

# docker-compose.yml volumes section:
volumes:
  - /data/aura-sessions:/data/aura-sessions

Logs will show:

[adk] Using FileSessionService — sessions persist to /data/aura-sessions

Cloud Deployment (Google Cloud Run)

One-click deploy

cd infra
cp terraform.tfvars.example terraform.tfvars   # fill in project_id, livekit_url, etc.
./deploy.sh

The script:

Stores LiveKit credentials in Secret Manager
Provisions Cloud Run, Artifact Registry, IAM, and Cloud Build trigger via Terraform
Builds and pushes the Docker image to Artifact Registry
Deploys to Cloud Run and prints the live URL

Manual Terraform

cd infra
cp terraform.tfvars.example terraform.tfvars   # edit values

terraform init
terraform plan
terraform apply

CI/CD

cloudbuild.yaml at the repo root is triggered automatically on every push to main. It:

Builds the Docker image (with layer caching from the :latest tag)
Pushes :<commit-sha> and :latest to Artifact Registry
Rolls out the new image to Cloud Run

The trigger is now configured and managed through Terraform in infra/main.tf, using the aura-deploy service account.

Live Deployment Proof

For the full operational runbook, see docs/OPERATION_MANAGE.md.

Demo & Documentation

Demo video:

Watch the full demo on Vimeo · Download mp4

Pitch deck: docs/GeminiLiveHackathon.pptx

Architecture & submission: docs/Aura_Design_Doc.md · docs/SUBMISSION_DRAFT.md

Environment Variables

See .env.example for the full list with descriptions. Key variables:

Variable	Required	Description
`LIVEKIT_URL`	✓	LiveKit server WebSocket URL
`LIVEKIT_API_KEY`	✓	LiveKit API key
`LIVEKIT_API_SECRET`	✓	LiveKit API secret
`GOOGLE_CLOUD_PROJECT_ID`	✓*	GCP project for Vertex AI
`GOOGLE_CLOUD_LOCATION`	—	GCP region (default: `us-central1`)
`VERTEX_AI_REASONING_ENGINE_ID`	—	Numeric ID of Vertex AI Reasoning Engine for cross-deployment session persistence (see Session Persistence)
`SESSION_PERSIST_DIR`	—	Local directory path for file-based session persistence (fallback when Reasoning Engine ID is not set)
`GOOGLE_API_KEY`	✓*	Google AI Studio key (preview path only)
`GEMINI_LIVE_MODEL`	—	Model name (default: `gemini-live-2.5-flash-native-audio`)
`GEMINI_TEXT_MODEL`	—	Text-only grading/summary model (default: `gemini-2.5-flash`)
`GEMINI_VOICE`	—	Voice name (default: `Aoede`)
`USER_IDLE_TIMEOUT_SECS`	—	Idle silence timeout (default: `120`)
`MAX_CALL_DURATION_SECS`	—	Hard call limit in seconds (default: `840`)

* One of GOOGLE_CLOUD_PROJECT_ID (Vertex AI) or GOOGLE_API_KEY (preview) is required.

Project Structure

├── bot/
│   ├── agent.py              # ADK LlmAgent, tool registry, LIVE_TOOL_DECLARATIONS
│   ├── bot.py                # FastAPI app — /livekit/session, /health
│   ├── audio/
│   │   ├── silero_vad.py     # Local UI-only speaking detector
│   │   ├── silero_vad.onnx   # Bundled Silero model artifact required at runtime
│   │   └── smart_turn.py     # Deprecated placeholder kept for historical context
│   ├── pipelines/
│   │   └── voice.py          # AuraVoiceSession — LiveKit ↔ Gemini Live bridge
│   ├── processors/
│   │   └── session_timer.py  # Call duration utility
│   └── prompts/
│       ├── grading_rubric.md             # Rubric used by post-call grading
│       ├── system_prompt.md              # Base persona (fallback)
│       ├── system_prompt_anon.md         # Anonymous user variant
│       ├── system_prompt_named_fast.md   # Named user — fast-start variant
│       ├── prompt_greeting_anon.md       # Opening greeting for anon users
│       ├── prompt_greeting_named.md      # Opening greeting for named users
│       └── prompt_round_*.md             # Per-round instruction overlays (8 files)
├── frontend/
│   ├── public/demo.html      # Voice UI (real-time transcript, metrics, summary, progress)
│   └── src/App.tsx           # Vite/React wrapper
├── infra/
│   ├── main.tf               # Cloud Run, Artifact Registry, IAM, Secret Manager
│   ├── variables.tf / outputs.tf / versions.tf
│   ├── terraform.tfvars.example
│   └── deploy.sh             # One-click bootstrap script
├── cloudbuild.yaml           # Cloud Build CI/CD pipeline
├── Dockerfile                # Multi-stage: Node.js build + Python 3.11 slim
├── docker-compose.yml        # Local single-container run
├── pyproject.toml            # Python dependencies (uv)
└── .env.example              # All environment variables documented

Tech Stack — Components, Roles & Why We Chose Them

LiveKit — WebRTC Transport Layer

What it does: LiveKit is a self-hostable WebRTC SFU (Selective Forwarding Unit) that manages real-time audio/video rooms. In Aura it provides the bi-directional audio channel between the browser microphone and the Cloud Run backend, plus a server-side data channel for structured events (transcript, grades, call summary).

Why LiveKit over raw WebRTC or other transports:

Concern	Raw WebRTC	LiveKit
NAT traversal / TURN	Manual STUN/TURN setup	Built-in, fully managed
Server-side audio access	Impossible without media server	`rtc.AudioStream` gives PCM frames directly in Python
Participant signalling	Custom protocol required	SDK handles join/leave/reconnect
Data channel	Unreliable ordering without SCTP work	`room.local_participant.publish_data()` — reliable ordered delivery
Scalability	Point-to-point only	SFU routes audio; scales to many participants
Python SDK	None official	`livekit` + `livekit-api` packages — first-class async support

Key integration points in Aura:

rtc.AudioStream(track) — pulls incoming browser mic PCM16 @ 16 kHz frame-by-frame
rtc.AudioSource(GEMINI_OUTPUT_SAMPLE_RATE, GEMINI_OUTPUT_CHANNELS) — pushes Gemini audio output back to browser
room.local_participant.publish_data(payload, reliable=True) — sends transcript lines, grade chips, and call summary JSON to the UI without a separate WebSocket
rtc.RoomEvent — drives session lifecycle (participant join/leave triggers session start/teardown)
livekit-api + api.AccessToken — backend mints short-lived JWT tokens per session; no credentials exposed to browser

Google ADK (`google-adk`) — Agent Orchestration

What it does: ADK (LlmAgent, Runner, VertexAiSessionService) wraps the Gemini Live bidi stream, handles tool dispatch, and manages session lifecycle. It eliminates writing a custom WebSocket loop for Gemini's BidiGenerateContent RPC.

Why ADK:

Tool calls from Gemini Live are dispatched to Python functions automatically — no if tool_name == "..." switching
VertexAiSessionService persists the full conversation event history to Vertex AI Agent Engine natively
RunConfig gives a clean surface for configuring VAD, speech, modalities, and session resumption in one place
LiveRequestQueue decouples audio ingestion from the ADK event loop — audio can be enqueued from the LiveKit receive loop without blocking

Gemini Live (`gemini-live-2.5-flash-native-audio`) — Voice Brain

What it does: Native audio model that speaks, listens, detects turn ends, handles barge-in, and evaluates interview answers — all in one bidi stream.

Why native audio (not text-to-speech + text):

Single round-trip: audio in → audio out in the same inference pass, no TTS post-step
Server-side VAD: turn detection runs inside the model pipeline, eliminating client-side buffering latency
enable_affective_dialog=True: Gemini modulates tone and pacing based on conversational context
STS latency 126–300 ms on conversational turns vs. 900–1400 ms with client Silero + SmartTurn

Silero VAD (`silero_vad.onnx` + `onnxruntime`) — Local UI Hints

What it does: A lightweight ONNX speech detection model that runs locally in-process on each 32 ms audio frame (512 samples @ 16 kHz).

Why a separate local VAD in addition to Gemini's server-side VAD:

Server VAD fires after Gemini processes the audio — there is a ~80–150 ms delay before the UI knows the user is speaking
Silero fires immediately on the local audio frame, enabling instant "user speaking" UI indicators and barge-in queue clear without waiting for a Gemini event
ONNX runtime is single-threaded, CPU-only, < 5 MB — no GPU, no network, negligible latency

FastAPI + Uvicorn — Backend HTTP/WebSocket Server

What it does: Serves three surfaces:

POST /livekit/session — mints LiveKit tokens, spawns the voice session task
GET /health — Cloud Run health check
Static file serving — frontend/dist/ (built React app)

Why FastAPI:

async def handlers integrate with the asyncio event loop used by LiveKit and ADK — no thread-pool overhead
Pydantic request/response models give automatic input validation and OpenAPI docs
Lifespan context manager handles pre-warm tasks cleanly at startup

Vertex AI Agent Engine — Session Persistence

What it does: Google-managed cloud storage for ADK session events. Each named candidate's history (questions asked, rubric grades, answer notes, round number) is persisted as ADK Event objects and survives container restarts, Cloud Run scale-out, and re-deployments.

Why Vertex AI Agent Engine over a database:

Native ADK integration — VertexAiSessionService is a drop-in for InMemorySessionService
No schema migrations, no connection pool, no DB maintenance
Events are JSON-serialisable and readable without a custom SDK
Automatic IAM-gated access — no credential rotation needed

Terraform + Cloud Build — Infrastructure as Code + CI/CD

What it does: All GCP resources (Cloud Run service, Artifact Registry repo, Secret Manager secrets, IAM bindings, Cloud Build trigger, Vertex AI Reasoning Engine) are declared in infra/main.tf. Any push to main triggers cloudbuild.yaml: build → tag with commit SHA → push to Artifact Registry → roll out to Cloud Run.

Why Terraform over console clicks:

Reproducible: terraform apply from a fresh project recreates the full stack in ~3 minutes
Auditable: every infra change is a Git commit
Cloud Build trigger is itself managed by Terraform — no manual console setup

Adding Tools

Tools are defined in bot/agent.py. To add a new tool:

Write a Python function and add it to TOOL_REGISTRY
Add a matching entry to LIVE_TOOL_DECLARATIONS (used by the Gemini Live session)
Add the function to the tools=[] list in build_adk_agent()

The same function is invoked whether the call comes from the ADK text runner or the live audio session.

HTTPS Deployment Options

Browser microphone access requires HTTPS on any public URL. Two GCP paths:

Option A — Cloud Run (recommended, HTTPS built-in)

Cloud Run is already provisioned by Terraform (infra/). Google's load balancer terminates TLS automatically — no Caddy or reverse proxy needed.

# One-command deploy (provisions + builds + deploys)
cd infra && ./deploy.sh

Your service is immediately available at https://aura-voice-agent-<hash>-uc.a.run.app.

Option B — Google Compute Engine VM + Caddy

Use this if you need a persistent VM (e.g. for testing, or if Cloud Run's request-based scaling doesn't fit your workload).

1. Create a GCE VM

gcloud compute instances create aura-vm \
  --project=YOUR_PROJECT_ID \
  --zone=us-central1-a \
  --machine-type=e2-standard-2 \
  --image-family=debian-12 \
  --image-project=debian-cloud \
  --tags=http-server,https-server \
  --metadata=startup-script='#! /bin/bash
    apt-get update
    apt-get install -y docker.io
    systemctl enable --now docker'

2. Open firewall ports

gcloud compute firewall-rules create allow-http-https \
  --allow=tcp:80,tcp:443 \
  --target-tags=http-server,https-server \
  --project=YOUR_PROJECT_ID

3. SSH in and start the container

gcloud compute ssh aura-vm --zone=us-central1-a

# On the VM:
git clone https://github.com/your-org/aura-sde-interview-agent.git
cd aura-sde-interview-agent
cp .env.example .env   # fill in values

# Optional: if you want Aura on 7863 behind Caddy instead of the default 7862
# echo 'PORT=7863' >> .env

docker compose up --build -d
curl http://127.0.0.1:${PORT:-7862}/health   # verify

4. Install Caddy and configure HTTPS

# On the VM:
apt-get install -y caddy
cp deploy/caddy/Caddyfile.example /etc/caddy/Caddyfile
# Edit /etc/caddy/Caddyfile:
# - replace aura.example.com with your real domain
# - if PORT is not 7862, also change 127.0.0.1:7862 to your chosen port
systemctl enable --now caddy

Point DNS — create an A record for your domain pointing to the VM's external IP:

gcloud compute instances describe aura-vm --zone=us-central1-a \
  --format='value(networkInterfaces[0].accessConfigs[0].natIP)'

Key points:

VM deployment is Docker plus Caddy: Docker runs the Aura container, Caddy terminates TLS on 443 and proxies to the local Aura port
Aura listens on port 7862 by default; if you set PORT=7863, update both docker compose and the Caddy upstream to 127.0.0.1:7863
The Caddyfile includes a keepalive transport directive to keep LiveKit WebSocket signalling alive
Caddy auto-renews Let's Encrypt certificates — no manual cert management needed

Health Check

curl https://your-cloud-run-url/health
# {"status":"ok","bot":"Aura","transport":"livekit","model":"gemini-live-2.5-flash-native-audio","active_rooms":0}

Name		Name	Last commit message	Last commit date
Latest commit History 27 Commits
bot		bot
deploy/caddy		deploy/caddy
docs		docs
frontend		frontend
infra		infra
tests		tests
.dockerignore		.dockerignore
.env.example		.env.example
.gitignore		.gitignore
Dockerfile		Dockerfile
README.md		README.md
cloudbuild.yaml		cloudbuild.yaml
docker-compose.yml		docker-compose.yml
pyproject.toml		pyproject.toml
uv.lock		uv.lock

Folders and files

Latest commit

History

Repository files navigation

Aura — Google SDE Interview Coach

Core Features

Demo Value

Architecture

VAD strategy — Gemini server-side turn detection + local UI hints

Latency analysis

Local Development

Prerequisites

1. Clone and install

2. Configure .env

3. Run the backend

4. Run the frontend (separate terminal)

5. Build the frontend for the backend-served app

6. Single-container run (Docker)

Local setup used in this repo right now

Session Persistence

Tier 1 — Vertex AI Agent Engine (recommended for Cloud Run)

Step 1 — Enable the API

Step 2 — Create the Reasoning Engine resource

Step 3 — Grant the service account access

Step 4 — Set the env var

Step 5 — Restart and verify

Tier 2 — File-based persistence (single VM / local dev)

Cloud Deployment (Google Cloud Run)

One-click deploy

Manual Terraform

CI/CD

Live Deployment Proof

Demo & Documentation

Environment Variables

Project Structure

Tech Stack — Components, Roles & Why We Chose Them

LiveKit — WebRTC Transport Layer

Google ADK (google-adk) — Agent Orchestration

Gemini Live (gemini-live-2.5-flash-native-audio) — Voice Brain

Silero VAD (silero_vad.onnx + onnxruntime) — Local UI Hints

FastAPI + Uvicorn — Backend HTTP/WebSocket Server

Vertex AI Agent Engine — Session Persistence

Terraform + Cloud Build — Infrastructure as Code + CI/CD

Adding Tools

HTTPS Deployment Options

Option A — Cloud Run (recommended, HTTPS built-in)

Option B — Google Compute Engine VM + Caddy

1. Create a GCE VM

2. Open firewall ports

3. SSH in and start the container

4. Install Caddy and configure HTTPS

Health Check

About

Topics

Resources

Uh oh!

Stars

Watchers

Forks

Packages 0

Uh oh!

Contributors

Uh oh!

Languages

2. Configure `.env`

Google ADK (`google-adk`) — Agent Orchestration

Gemini Live (`gemini-live-2.5-flash-native-audio`) — Voice Brain

Silero VAD (`silero_vad.onnx` + `onnxruntime`) — Local UI Hints

Packages
