DynaG

Dynamic System solver for reinforcement learning environment. It solves ODE with $4^{th}$ order Runge-Kutta methods.

DynaG has

• OpenAI GYM environment integration.
• 3D rendering with OpenGL.
• Dynamics and rendering wrintten in C++

properties.

DynaG has two seperate APIs. For dynamic system calculation DynaG-dynamcis and for rendering DynaG-renderer is used.

---

DynaG-Heli

6-DOF Helicopter Environment with DynaG. Implementation structure can be found in here.

This helicopter environment is written for flight tasks with reinforcement learning and has

• Realistic Dynamic Model based on Minimum Complexity Helicopter Model (Heffley and Mnich) In addition, inflow dynamics are added and model is adjusted so that it covers multiple flight conditions.
• Dryden Turbulence model is added to make the environment stochastic.

properties.

Action Space

Num	Act	Unit	Min	Max
0	Collective		-1	1
1	Lon. Cyclic		-1	1
2	Lat. Cyclic		-1	1
3	Pedal		-1	1

Observation Space

Num	Obs	Unit	Min	Max
0	power	$hp $	0	∞
1	lon. air speed	$ft/s $	-∞	∞
2	lat. air speed	$ft/s $	-∞	∞
3	down air speed	$ft/s $	-∞	∞
4	lon. speed	$ft/s $	-∞	∞
5	lat. speed	$ft/s $	-∞	∞
6	down speed	$ft/s $	-∞	∞
7	lon. acceleration	$ft/s^2$	-∞	∞
8	lat. acceleration	$ft/s^2$	-∞	∞
9	down acceleration	$ft/s^2$	-∞	∞
10	north velocity	$ft/s $	-∞	∞
11	east velocity	$ft/s $	-∞	∞
12	descend rate	$ft/s $	-∞	∞
13	roll angle	$rad $	-π	π
14	pitch angle	$rad $	-π	π
15	yaw angle	$rad $	-π	π
16	roll rate (body)	$rad/s $	-∞	∞
17	pitch rate (body)	$rad/s $	-∞	∞
18	yaw rate (body)	$rad/s $	-∞	∞
19	x loc (earth)	$ft $	-∞	∞
20	y loc (earth)	$ft $	-∞	∞
21	sea altitude	$ft $	0	∞
22	ground altitude	$ft $	0	∞
23	coll. angle	$rad $	-∞	∞
24	lon. angle	$rad $	-∞	∞
25	lat. angle	$rad $	-∞	∞
26	pedal angle	$rad $	-∞	∞
27	coll. angle rate	$rad/s $	-∞	∞
28	lon. angle rate	$rad/s $	-∞	∞
29	lat. angle rate	$rad/s $	-∞	∞
30	pedal angle rate	$rad/s $	-∞	∞
31	turbulance u speed	$ft/s $	-∞	∞
32	turbulance v speed	$ft/s $	-∞	∞
33	turbulance w speed	$ft/s $	-∞	∞

Tasks

For now only one task is available.

Environment	Details
Hover-v0	Hover

---

Tested OS

Environment tested on these OSs. If you have any problem, probably shared libraries for rendering make it, please look at renderer build.

Receiving max FPS with NVIDIA 1070-TI with Intel i7-8700K given in the table.

Tested OS	Max FPS
Windows 10	1200
Ubuntu 18.04	1300
Ubuntu 16.04	1300

For the user who has lower than the version of Ubuntu 16.04 (like Ubuntu 14.04 etc.) or other Linux distros, please re-compile dependent libraries. Re-compile instruction can be found at renderer build. Also, dynamics should be re-compiled. Re-compile instruction can be found at dynamics build.

---

Setup

Clone the repo.

git clone https://github.com/MGokcayK/DynaG.git

Run following command.

pip install .

or

pip install -e .

---

Usage

Create environment by either,

from dynag import Hover
env = Hover()

or

import gym
import dnyag
env = gym.make("Hover-v0")

The rest is usual as of any GYM environment !

---

@mastersthesis{MGK-Master-2022,
    author = {Mehmet Gökçay Kabataş},
    title = {{Pekiştirmeli Öğrenme İçin Bir Helikopter Ortamı Geliştirilmesi}},
    school = {Kocaeli Üniversitesi},
    address = {Türkiye},
    year = {2022}
}

---
